Project introduction
ISOP technology can be used in DC transformers and power electronic transformers.power electronic transformer (PET), also known as solid state transformer, is a new intelligent device based on power electronic transformation technology to realize the traditional transformer voltage transformation and electrical isolation.Its main characteristics are small size, light weight, high controllability, can concentrate a variety of functions, so it has a wide range of application prospects in the power system and other fields, such as smart grid, renewable energy system integration, power grid energy storage, data centers and ships and electric locomotives.
Core technology
The ACM-100 high-end industrial control platform is adopted to realize the control and protection redundancy system of power electronic transformer (ISOP), and complete the IGBT valve control and protection functions with a cycle of 50 microseconds
PDH-300 universal measurement and control hardware platform is used to realize the field data acquisition and control of primary equipment
The high speed data acquisition and recording equipment VM21 is used to realize data recording and fault location of power electronic transformer system.
DYNAS monitoring software is used to realize the local monitoring system of the control panel cabinet, which is used for debugging and data monitoring.
